The ZHENGFEI EC-17 combines functionality with aesthetics, featuring a beautiful walnut wood base and gold-finished brass heating components. This premium manual hot stamping machine is perfect for artisans who value both performance and craftsmanship. The digital temperature controller ensures precise heat management for consistent results.
Each kit includes 1 holder of your choice. Select based on your stamp size.
For stamps 5×7cm
For stamps 8×10cm
For stamps 10×13cm
Adjustable Multi-Size
No adapters. No converters. We handle everything.
We automatically match power supply and plug type based on your shipping address. No third-party adapters needed.
Fully certified for Europe (CE) and USA (FCC). Meets strict international safety standards.
Premium hardwood base for stability and longevity. Each piece unique in grain pattern.
The ZHENGFEI EC-17 combines functionality with aesthetics, featuring a beautiful walnut wood base and gold-finished brass heating components. This premium manual hot stamping machine is perfect for artisans who value both performance and craftsmanship. The digital temperature controller ensures precise heat management for consistent results.
| Parameter | Specification |
|---|---|
| Model | EC-17 |
| Heating Plate Size | 5×7 cm / 8×10 cm / 10×13 cm (customizable) |
| Temperature Range | 50-350°C (122-662°F) |
| Temperature Accuracy | ±3°C (high-precision controller) |
| Power Rating | 150W (5×7), 200W (8×10), 250W (10×13) |
| Voltage | 110V/220V AC, 50/60Hz (universal) |
| Heating Element | Aluminum alloy plate with embedded ceramic heater |
| Temperature Control | Digital PID controller with red LED display |
| Display Type | 3-digit LED (shows current temperature) |
| Control Precision | 1°C increments |
| Operation Method | Manual lever press with ergonomic handle |
| Pressure Range | Adjustable, ~150-250 kg maximum |
| Worktable Material | Anodized aluminum with laser-etched grid (1cm spacing) |
| Worktable Size | 12×15 cm |
| Base Material | Solid walnut wood (25mm thick) |
| Base Dimensions | 36×26 cm |
| Heating Plate Material | Gold-plated brass (decorative + functional) |
| Frame Material | Steel with black powder coating |
| Mold Mounting | M8 threaded holes, compatible with standard brass molds |
| Positioning Clamps | 2× adjustable spring clamps included |
| Heat-up Time | 2-4 minutes to 200°C |
| Power Cable Length | 1.5m with grounded plug |
| Machine Dimensions | 32×22.5×36 cm (L×W×H) |
| Net Weight | 6.8 kg |
| Gross Weight | 8.5 kg (with packaging) |
| Packaging | Reinforced cardboard with foam inserts |
| Safety Features | Over-temperature protection, grounded cord |
| Certification | CE compliant (EU), UL-compatible components |
Walnut Wood Base Benefits:
Gold-Plated Heating Components:
Precision Temperature Controller:
Every craft has its nuances. Tell us about your primary medium—whether it’s vegetable-tanned leather, porcelain, or lost-wax casting—and our master artisan will reply within 24 hours with specific pressure techniques and compatibility advice. No obligation, just expertise.
